Clean Wardrobe
1
Application
Widely used for clean clothing storage in pharamaceutical, preparations, electronics, precision instruments, meters, food and other special occasions such as clean room, laboratory, operating room, GMP plant etc, in order to prevent from any air pollution of clean clothes during collection and transmission process.
2
Convenience to move
KLC series clean wardrobe, also known as dust-free wardrobe, is a wardrobe dedicated to use in clean room, the use of three shock absorption measures and removable brake casters helps to reduce the vibration and easy to move, the wheels set beneath the clean wardrobe makes the movement flexible and convenient.
3
Customized
KLC clean wardrobe adopt 99.99%@0.3um filtration efficiency, optional components includes LED, UV lamps etc.
| Item | Clean wardrobe / Dust-free wardrobe | ||
|---|---|---|---|
| Model | CW-001 | CW-002 | CW-003 |
| Module size (W*L*H)mm | 1000*700*2300 | 1500*700*2300 | 2000*700*2300 |
| Static pressure box material | High quality epoxy powder coated / Stainless steel | ||
| Average wind speed (m/s) | 0.35~0.55 | ||
| Noise db 1 meter below the HEPA filter | 55~63 | ||
| Power supply | 220V/50 Hz | ||
| Fan | AC centrifugal fan | ||
| HEPA efficiency | 99.99%@0.3μm | ||
| Vibration (mm/s) | 0.2~0.5 | ||
| Cleanliness | Class static 100 (ISO14644-1 standard) | ||
⚙️Parameter
- 1. Fan
- 2. Control panel
- 3. HEPA filter
- 4. UV lamp (optional)
- 5. Laminar flow diffuser
- 6. Cabinet
- 7. Acrylic glass door
- 8. Universal wheel
- 9. Removable shelf
- 10. Stainless steel clothes hanging rod
- 11. Power connector
