Activated Carbon V-bank Filter
Adaptive Efficiency G4 / M5 / M6 / F7 / F8 / F9
Product Features
- Designed to efficiently remove particulates that contaminate the indoor air as well as a wide range of oders at high air flows.
- Activated carbon is encapsulated in synthetic media mini-pleated which prevents dusting, minimizes pressure drop and ensures high effective area.
- Synthetic media is optional to choose fromG4~F9filtration efficiency which could provide dual purification effect.
- The activated carbon granule loaded could be modified to control difficult contaminants, such asH2S, acid gases, formaldehyde, ammonia, aldehydes and amines.
- Good appearance, convenient installation, easy maintenance.
- High impact ABS frame is corrosion free and fully incinerable.
+44 7479 496191
Call
info@filtravo.com
Application
From indoor climate control systems such as airports, hospitals, museums, laboratories, pharmacies, commercial buildings, etc., where environment obtain strange odors, gases or acid vapors.
Material and Operation Conditions
| Media | Carbon granule laminated fiber media / Chemically treated or blended carbon granule laminated fiber media |
| Frame | Plastic (ABS) treated |
| Sealant | Two-component polyurethane glue |
| Gasket | EVA/EPDM |
| Separator | Hot melt bead |
| Frame thickness (mm) | 292 |
| Max. Temperature (°C) | 50 |
| Max. Humidity | 95% |
Technology Parameters
* Customized design is available
| Model | Nominal size(inch)(WxHxD) |
Actual size(mm)(WxHxD) |
Air flow(m³/h) | Initial pressure(Pa) | Media area(m²) | Velocity(m/s) | Odor removal rate |
Pack no |
|---|---|---|---|---|---|---|---|---|
| K4V-CP-01 | 24×12×12 | 592×287×292 | 1700 | 68 | 2.60 | 2.54 | 90% | 4 |
| K4V-CP-02 | 24×20×12 | 592×495×292 | 2600 | 68 | 4.74 | 2.54 | 90% | 4 |
| K4V-CP-03 | 24×24×12 | 592×592×292 | 3400 | 68 | 5.85 | 2.54 | 90% | 4 |
